P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
Installation iPRO-RC™ Series Banknote Recycler Section 2
Caution: DO NOT use alcohol, solvents,
abrasive cleaning agents, or citrus
based cleaners that can damage the
plastic surface of the device when
cleaning it. The lenses can become
clouded by chemical evaporation
residue that may cause acceptance
errors.
Caution: Be sure to use non-flammable
compressed air only.
NOTE: When closing the iPRO’s Transport
Unit or the Recycler Unit’s Upper Guides,
ensure they firmly click into place when
closed. Also, when re-assembling the
iPRO-RC Unit, ensure that it re-seats
correctly into place when reassembly is
complete.
NOTE: Wipe and clean all of the Green-
colored Rollers and Belts shown in Figure
2-10 on page 2-12 using a slightly damp
(not wet), lint-free Micro-fiber cloth.
Caution: DO NOT allow liquids to drip
into the Unit’s interior; otherwise, the
Unit may not operate correctly.
NOTE: Cleaning the Pick Roller should be
performed only when appropriate Operator
training has been completed!
Figure 2-9 Sensor and Roller Cleaning
Figure 2-9 Sensor and Roller Cleaning
Lens
Roller
Lint-free Cloth/Cotton Swab/Air
Before
Cleaning
After
Cleaning
Belt
To Next Page
