Table 10-2: Quick Setup Parameters — M1 ➔ G1.1, continued
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.1.13 StPt Source
Hand
0 3 2 113 Local speed setpoint selection:
0 = analog input AI-1
1 = analog input AI-2
2 = Speed Setpoint from Keypad
3 = Motor Potentiometer
P1.1.14 Start Srce Auto 1 4 2 114 Parameter for Remote Start/
Stop/Reverse control location.
Default = DI-1 Start
1 = Keypad
2 = DI-1 Start
3 = I/O Three Wire
4 = Fieldbus
P1.1.15 StPt Source Auto 0 4 0 115 PI-setpoint selection:
0 = analog input AI-1
1 = analog input AI-2
2 = PI Setpoint from Keypad
3 = Motor Potentiometer
4 = PI Setpoint from Fieldbus
P1.1.16 PI-Input Source 0 2 0 1106 PI-Controller Input Source
Selection:
Default #0 = (A) AI-1
0 = (A) AI-1
1 = (A) AI-2
2 = Fieldbus, Process Data 1
3 = Min. Both
4 = Max. Both
5 = Ave. Both
P1.1.17 PI-Contr. P-Gain 0.00 10.00 0.10 1109 P-Term (Gain) for the
PI-Controller
P1.1.18 PI-Contr. I-Time 0.00 320.00 s 30.00 1110 I-Term (Integral Time) for the
PI-controller
P1.1.19 PI-Deadband 0.0 100.0 % 0.0 1111 Deadband for the PI-controller
P1.1.20 PI-Mode 0 1 0 1112 PI-controller acting mode
P1.1.21 AutoAccelTime 0.1 3000.0 s 60.0 1113 Acceleration time, when in
AUTO mode
P1.1.22 AutoDecelTime 0.1 3000.0 s 60.0 1114 Deceleratin time, when in AUTO
mode
