Johnson Controls VSD Series User Manual

Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828 For more information visit: www.johnsoncontrols.com A-11
November 2009
Figure A-10: VSD Series Open Drive Dimensions, TYPE 1 and TYPE 12, FR8
Table A-9: VSD Series Open Drive Dimensions, FR8
Frame Size Voltage hp (VT)
Approximate Dimensions in Inches (mm)
Knockout @
Inches (mm)D1 H1 W1
FR8 230V 50 – 75 13.5 (344) 30.1 (764) 11.4 (289) 3 @ 1.1 (28)
480V 100 – 150
575V 60 – 100 2 @ 2.32 (59)
W1
D1
H1
