VSD Series Drives User Manual Powered by Eaton Technology
15-28 For more information visit: www.johnsoncontrols.com LIT-1201828
November 2009
Keypad Control Parameters
Unlike the parameters listed above, these parameters are located in the M2 menu of the
control keypad. The keypad reference and PI setpoint parameters do not have ID numbers.
Table 15-6: Preset Speeds
1009 Keypad direction
0 Forward: The rotation of the motor is forward, when the keypad is the
active control place.
1 Reverse: The rotation of the motor is reverse, when the keypad is the
active control place.
For more information, see Chapter 6, Keypad Control Menu (M2).
1010 STOP button activated
To make the STOP button a “hotspot” which always stops the drive regardless of the
selected control place, set the value of this parameter to 1.
R2.1 Keypad reference
The frequency reference can be adjusted from the keypad with this parameter.
The output frequency can be copied as the keypad reference by pushing the STOP
button for 3 seconds when you are on any of the pages of menu M2. For more
information, see Chapter 6, Keypad Control Menu (M2).
R2.4 PI Setpoint
The PI controller keypad reference can be set between 0% and 100%. This reference
value is the active PI reference if ID115 = 2. Units are application dependent.
1701
to
1707
Preset Speed
Digital Input(s) for …
StatusPreset Speed 1 Preset Speed 2 Preset Speed 3
000OFF
1 0 0 Preset Speed 1
0 1 0 Preset Speed 2
1 1 0 Preset Speed 3
0 0 1 Preset Speed 4
1 0 1 Preset Speed 5
1 1 0 Preset Speed 6
1 1 1 Preset Speed 7
Code Parameter Min. Max. Unit Step Default
ID
Number Description
P1.10.1 Preset Speed 1 0 100.0 % 0.1 30.0 1701 Preset speeds when
Digital Inputs are
programmed
P1.10.2 Preset Speed 2 0 100.0 % 0.1 40.0 1702
P1.10.3 Preset Speed 3 0 100.0 % 0.1 50.0 1703
P1.10.4 Preset Speed 4 0 100.0 % 0.1 60.0 1704
P1.10.5 Preset Speed 5 0 100.0 % 0.1 70.0 1705
P1.10.6 Preset Speed 6 0 100.0 % 0.1 80.0 1706
P1.10.7 Preset Speed 7 0 100.0 % 0.1 90.0 1707
