Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828
For more information visit: www.johnsoncontrols.com 6-7
November 2009
Keypad Control Menu (M2)
In the Keypad Control Menu, you can set the frequency reference, choose the motor
direction for keypad operation, and determine if the STOP button will be active at all
times. See Figure 6-5.
Figure 6-5: Keypad Control Menu
R2.1
Speed
Setpoint
Range: 0 — Max. Frequency
Units: %
Speed Setpoint
This displays and allows the operator to edit the keypad speed setpoint. A change
takes place immediately. This reference value will not influence the output
frequency unless the keypad has been selected as the active control place.
P2.2
Keypad
Direction
Range: Forward, Reverse Default: Forward
Keypad Direction
This allows the operator to change the rotation direction of the motor. This setting
will not influence the rotation direction of the motor unless the keypad has been
selected as the active control place.
P2.3
Stop Button
Active
Range: Yes, No Default: Yes
StopButtonActive
By default, pushing the STOP button will always stop the motor regardless of the
selected control place. If this parameter is set to No, the STOP button will stop the
motor only when the keypad has been selected as the active control place. The
Start Command must be toggled or re-issued to restart the drive.
R2.4
PI Setpoint
Range: Application Dependent Default: Application
Dependent
PI Setpoint
PI regulators setpoint. Parameter not available in Remote Input Application.
P2.5
PI Setpoint
Default
Range: Application Dependent Default: Application
Dependent
PI StPt Default
PI regulators default setpoint. This parameter is set in Start-Up Wizard. Parameter
not available in Remote Input Application.
M2 Keypad Control
R2.1 Speed Setpoint
P2.2 Keypad Direction
. . .
P2.5 PI-StPt Default
To Next Page
