Johnson Controls VSD Series User Manual

VSD Series Drives User Manual Powered by Eaton Technology
A-8 For more information visit: www.johnsoncontrols.com LIT-1201828
November 2009
Dimensions
Figure A-7: TYPE 1 and TYPE 12 VSD Series Open Drive Dimensions, FR4, FR5 and FR6
Table A-5: VSD Series Open Drive Dimensions
Frame
Size Voltage hp (VT)
Approximate Dimensions in Inches (mm)
Weight
Lbs.
(kg)
Knockouts
@ Inches
(mm)
H1 H2 H3 D1 D2 D3 W1 W2 W3
R1
dia.
R2
dia. N1 (O.D.)
FR4 230V 1 – 3 12.9
(327)
12.3
(313)
11.5
(292)
7.5
(190)
2.5
(64)
5.0
(126)
5.0
(128)
3.9
(100)
— .5
(13)
.3
(7)
11.0
(5)
3 @ 1.1
(28)
480V 1-1/2 –
7-1/2
FR5 230V 5 – 10 16.5
(419)
16.0
(406)
15.4
(391)
8.4
(214)
2.7
(68)
5.7
(148)
5.7
(144)
3.9
(100)
— .5
(13)
.3
(7)
17.9
(8)
2 @ 1.5
(37)
1 @ 1.1
(28)
480V 10 – 20
FR6 230V 15 – 20 22.0
(558)
21.3
(541)
20.4
(519)
9.3
(237)
2.7
(68)
6.7
(171)
7.6
(195)
5.8
(148)
— .7
(18)
.4
(9)
40.8
(19)
3 @ 1.5
(37)
480V 25 – 40
575V 3 – 30
EATON
D1 W2
W1
R2
R1
R2
H3
H2
H1
D2
D3
Knockouts
W3
