Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828
For more information visit: www.johnsoncontrols.com 12-19
November 2009
Table 12-13: Monitoring Menu, continued
Operate Menu — M8
The Operate Menu provides an easy to use method of viewing key numerical Monitoring
Menu items. It also allows the setting of the keypad frequency reference. See Chapter 6 for
more information.
Code Parameter Min. Max. Unit Default
ID
Number Description
V7.20 Status Word -32768 32767 0 20 b0 = Drive Ready
b1 = Run Enable
b2 = Drive Running
b3 = Drive Reversing
b4 = General Fault
b5 = General Warning
b6 = Preset Speed Active
b7 = Motor Regulator active
b8 = Output speed supervision
indication
b9 = Setpoint speed supervision
indication
b10 = HAND Control indication
b11 = AUTO Control indication
b12 = D-IN Firemode
b13 = Damper control signal
b14 = Bypass mode status
indication
b15 = Bypass running
V7.21 PI-Setpoint (-10000) (10000)
WC/
PA
(0) 21
V7.22 PI-Input (-10000) (10000) (0) 22 Actual Sensor Value
V7.23 PI-Error (-10000) (10000) (0) 23
V7.24 PI-Output 0.0 100.0 % 0.0 24
V7.25 RO-1 RO-2 RO-3 0 7 0 25 Monitoring the OPTB5 relay
outputs.
G7.26 Multimonitor Displays three monitor values
simultaneously
