Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828
For more information visit: www.johnsoncontrols.com 14-17
November 2009
Keypad Control Parameters — M2
This menu provides the parameters for the setting of the keypad speed setpoint, the selection
of motor direction when in keypad operation, and when the STOP button is active.
Table 14-12: Keypad Control Parameters — M2
Keypad Control Parameter ID Numbers are listed separately on Page 15-28.
Menus — M3 to M6
Menus M3 to M6 provide information on the Active Faults, Fault History, System Menu
settings and the Expander Board setup. These menu items are explained in detail in
Chapter 6.
Code Parameter Min. Max. Unit Default
ID
Number
Description
R2.1 Speed Setpoint 0.0 100.0 % 0.0 Keypad Speed Setpoint.
P2.2 Keypad Direction 0 1 0 1009 Reverse request active from the
panel
0 = Forward
1 = Reverse
P2.3 StopButton
Active
0 1 1 1110 Stop button (Keypad) always
active (Yes/No)
R2.4 PI-Setpoint (-10000) (10000) (800)
P2.5 PI-Setpoint
Default
(-10000) (10000) 1011 PI-regulators default setpoint
