Table 6-10: Hardware Information
Table 6-11: Expander Board Information
See option board manual for additional information data.
Table 6-12: Drive Output Phase Current Measurement
S5.8.5
Hardware
Information
Hardware
The Hardware information page provides information on the following hardware-
related topics:
Number Content
I5.8.5.1 Nominal power of the unit
I5.8.5.2 Nominal voltage of the unit
E5.8.5.3 Brake chopper
E5.8.5.4 Brake resistor
E5.8.5.5 Power unit serial number
S5.8.6
Expander
Board
Information
Expander boards
This parameter and its sub-items provide information about the basic and option
boards plugged into the control board as shown in Table 6-11. Note that the “x” in
the table refers to the sequential number of the slot, with slot A being “1” and slot
E being “5”.
Number Content
E5.8.6.x Slot “x” board identification
E5.8.6.x.1 Operating state
E5.8.6.x.2 Software version
S5.8.7
Debug Menu
Debug
This menu is meant for advanced users and application designers. Contact the
factory for any assistance needed.
S5.9
Power
Monitor
power monitor
Number Content
V5.9.1 IU filtered, Phase 1
V5.9.2 IV filtered, Phase 2
V5.9.3 IW filtered, Phase 3
S5.10
Reserved
Parameter not displayed, reserved for future use.
S5.11
Power Multi-
monitoring
power multimon
Displays all three output phase currents simultaneously.
