Johnson Controls VSD Series User Manual

VSD Series Drives User Manual Powered by Eaton Technology
A-10 For more information visit: www.johnsoncontrols.com LIT-1201828
November 2009
Figure A-9: VSD Series Open Drive Dimensions, TYPE 1 and TYPE 12, FR7
Table A-8: VSD Series Open Drive Dimensions, FR7
Frame
Size Voltage
hp
(VT)
Approximate Dimensions in Inches (mm)
Weight
Lbs. (kg)
Knockouts
@ Inches
(mm)
H1 H2 H3 D1 D2 D3 W1 W2
R1
dia.
R2
dia. N1 (O.D.)
FR7 230V 25 – 40 24.8
(630)
24.2
(614)
23.3
(591)
10.1
(257)
2.7
(68)
7.5
(190)
9.3
(237)
7.5
(190)
.7
(18)
.4
(9)
77.2
(35)
3 @ 1.85
(47)
480V 50 – 75
575V 40 – 50
W2
H1
D1
D2
Knockouts
R2 R2R1
D3
H2
H3
W1
