VSD Series Drives User Manual Powered by Eaton Technology
5-2 For more information visit: www.johnsoncontrols.com LIT-1201828
November 2009
Catalog Number Selection
Table 5-1: VSD Series IntelliPass/IntelliDisconnect Drives Selection Chart
All horsepower ratings are Variable Torque (VT).
1 – 30 hp 208/230V AC; 1 – 75 hp 480V AC
N2/XT Communications selectable on drive keypad.
SA = Sensor Actuator Bus for FEC Interface.
Options List: 00 = None
P6 = 3rd Contactor Drive Isolation (IntelliPass only)
Note: All VSD Series IntelliPass Drives incorporate two factory installed Auxiliary Contacts (formerly the “K9” option).
Code Number V S 1 1 A - N
Base Product VS = Variable Speed
Drive Prefix
Horsepower (VT)
001 = 1.0 hp to
075 = 75 hp
Voltage 1 = 208V
2 = 230V
4 = 480V
Enclosure Rating 1 = TYPE 1
Enclosure Style 1 = IntelliPass
4 = IntelliDisconnect
Revision # A = Rev 1 (Americas)
Separator (–)
Communications
0 = None
N = N2/XT/SA
Bus Comm (N2 by default)
L = L
ONWORKS
®
Network
Option 1
See Options List
Option 2
See Options List
To Next Page
