Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828
For more information visit: www.johnsoncontrols.com 11-3
November 2009
Parameter Lists
On the next pages you will find the lists of parameters within the respective parameter
groups. The parameter descriptions are given by ID number in Chapter 15.
Column explanations:
Quick Setup Parameters — M1 ➔ G1.1
Table 11-2: Quick Setup Parameters — M1 ➔ G1.1
Code = Location indication on the keypad; Shows the operator the present
parameter number
Parameter = Name of parameter
Min. = Minimum value of parameter
Max. = Maximum value of parameter
Unit = Unit of parameter value; Given if available
Default = Value preset by factory
ID = ID number of the parameter for reference to Chapter 15
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.1.1 Min Frequency 0.00 Max_
Frequency
Hz 12.00 101 Minimum output frequency,
f[Hz].
P1.1.2 Max Frequency FreqMin 320.00 Hz 60.00 102 Maximum output frequency,
f[Hz].
P1.1.3 Acceleration
Time
0.1 3000.0 s 60.0 103 Time from 0 Hz to maximum Hz.
P1.1.4 Deceleration
Time
0.1 3000.0 s 60.0 104 Time from maximum Hz to 0 Hz.
P1.1.5 Motor NP Voltg 180 Motor
VoltageMax
V 400 105 Motor nameplate voltage in
Volts.
P1.1.6 Motor NP Freq 8.00 320.00 Hz 60.00 106 Motor nameplate frequency in
Hertz.
P1.1.7 Motor Nom
Speed
24 20000 rpm 1720 111 Motor nameplate speed in Rpm.
P1.1.8 Motor Nom
Currnt
Motor
CurrentMin
Motor
CurrentMax
A 5.40 108 Motor nameplate current, I[A]
P1.1.9 Power Factor 0.30 1.00 0.85 109 Motor power factor. (Cos Phii)
P1.1.10 Service Factor 0.10 2.00 1.00 110 Motor service factor. This will
calculate the motor current limit.
(MotorNomCurrent x Service
Factor)
P1.1.11 Current Limit Motor
CurrentMin
Motor
CurrentMax
A 7.00 107 Output current limit of the unit in
Amps.
P1.1.12 Start Srce Hand 1 3 1 112 Parameter for Local Start/Stop/
Reverse control location.
Default = Keypad
1 = Keypad
2 = DI-1 Start
3 = I/O Three Wire
To Next Page
