Keypad Control Parameters — M2
This menu provides the parameters for the setting of the keypad speed setpoint, the selection
of motor direction when in keypad operation, and when the STOP button is active.
Table 10-12: Keypad Control Parameters — M2

Keypad Control Parameter ID Numbers are listed separately on Page 15-28.
Menus — M3 to M6
Menus M3 to M6 provide information on the Active Faults, Fault History, System Menu
settings and the Expander Board setup. These menu items are explained in detail in
Chapter 6.
Monitoring Menu — M7
The monitored items are the actual values of parameters and signals as well as the status
and measurements of other elements. Monitored items cannot be edited.
See Chapter 6 — Menu information item M7, for more information.
Table 10-13: Monitoring Menu
Code Parameter Min. Max. Unit Default
ID
Number

Description
R2.1 Speed Setpoint 0.0 100.0 % 0.0 Keypad Speed Setpoint.
P2.2 Keypad Direction 0 1 0 1009 Reverse request active from the
panel
0 = Forward
1 = Reverse
P2.3 StopButton
Active
0 1 1 1110 Stop button (Keypad) always
active (Yes/No)
R2.4 PI-Setpoint PI_Setpoint_
Min
PI_Setpoint_
Max
% 0.0
P2.5 PI-Setpoint
Default
PI_Setpoint_
Min
PI_Setpoint_
Max
1011 PI-regulators default setpoint
Code Parameter Min. Max. Unit Default
ID
Number Description
V7.1 Output
Frequency
-320.00 320.00 Hz 0.00 2 Output frequency to the motor
V7.2 Actual Speed -320.0 320.0 % 0.0 1 Output speed to the motor
V7.3 Speed Setpoint -320.0 320.0 % 0.0 3 Monitored speed setpoint. This
will show also the speed
setpoint below the minimum
frequency.
V7.4 Motor Speed -10000 10000 rpm 0 4 Calculated motor speed in rpm
V7.5 Motor Current 0.0 Motor
CurrentMax
A 0.0 5
V7.6 Motor Torque -300.0 300.0 % 0.0 6 [R] Motor torque as % value,
+1000 equals +100.0 %
pos = clockwise,
neg = counterclockwise
V7.7 Motor Power -300.0 300.0 % 0.0 7
V7.8 Motor Voltage 0.0 1000.0 V 0.0 8 Measured motor voltage
