Johnson Controls VSD Series User Manual

VSD Series Drives User Manual Powered by Eaton Technology
A-14 For more information visit: www.johnsoncontrols.com LIT-1201828
November 2009
Figure A-13: VSD Series Open Drive Dimensions, TYPE 1 and TYPE 12 FR9 with Flange Kit
Table A-13: Dimensions for VSD Series Open Drive, FR9 with Flange Kit
Frame
Size Voltage hp (VT)
Approximate Dimensions in Inches (mm)
W1 W2 W3 W4 W5 H1 H2 H3 H4 H5 H6 H7 D1 D2 D3 Dia.
FR9 230V 100 20.9
(530)
20.0
(510)
19.1
(485)
7.9
(200)
.2
(6)
51.7
(1312)
45.3
(1150)
16.5
(420)
3.9
(100)
1.4
(35)
.4
(9)
.1
(2)
24.9
(362)
13.4
(340)
4.3
(109)
.8
(21)
480V 200 – 250
575V 125 – 200
.20 (5)
Dia.
H4
H2
D2
Dia.
D1
D3
H4
W1
H7
W5
W3
W4
H3 H3 H3 H5H5
H6
H1
W4
W2
Flange Opening
FR9
