VSD Series Drives User Manual Powered by Eaton Technology
6-20 For more information visit: www.johnsoncontrols.com LIT-1201828
November 2009
Monitoring Menu (M7)
The Monitoring Menu items are meant for viewing parameter values during operation.
Monitored values are updated every 0.3 sec. Monitored items are identified by item numbers
V7.1 to V1.xx, where “xx” varies by application. Table 6-13 provides an example of the
monitored values for the Generic PI application.
Monitored parameters are not editable from this menu (See Parameter Menu [M1] to change
parameter values).
Table 6-13: Monitoring Menu Items — Generic PI Application Example
Units will vary depending on active application.
Not available in Remote Input application.
Figure 6-10: Digital Inputs — DI-1, DI-2, DI-3 Status
Code Signal Name Unit ID Description
V7.1 Actual speed % 1 Actual motor speed between min and max
frequency
V7.2 Output frequency Hz 2 Output frequency to motor
V7.3 Speed Setpoint % 3 Speed Setpoint
V7.4 Motor speed rpm 4 Calculated motor speed in rpm
V7.5 Motor current A 5 Motor current
V7.6 Motor torque % 6 Calculated torque as a percentage of nominal
torque
V7.7 Motor power % 7 Calculated motor shaft power
V7.8 Motor voltage V 8 Calculated motor voltage
V7.9 DC-Bus voltage V 9 DC-Bus voltage
V7.10 Unit temperature °F 10 Heatsink temperature
V7.11 Motor temperature % 11 Calculated motor temperature
V7.12 Analog input 1 V 12 Analog input AI-1
V7.13 Analog input 2 mA 13 Analog input AI-2
V7.14 DI-1, DI-2, DI-3 14 Digital input status (Figure 6-10)
V7.15 DI-4, DI-5, DI-6 15 Digital input status (Figure 6-11)
V7.16 DO-1, RO-1, RO-2 16 Digital and relay output status (Figure 6-12)
V7.17 Analog Iout mA 17 Analog output AO-1
V7.18 Active Fault Code 18 Active Fault Code for fieldbus use
V7.19 Active Warning Code 19 Active Warning Code for fieldbus use
V7.20 Status Word 20 Status Word for fieldbus use
V7.21
PI Setpoint %
21 PI Setpoint
V7.22
PI Input %
22 PI Input
V7.23
PI error %
23 Calculated error between PI actual and
reference values
V7.24
PI output % 24 PI output (speed reference when PI active)
G7.25 Multimonitor Displays three selectable monitoring values
V1.14
DI-1, DI-2, DI-3
OFF ON OFF
