Johnson Controls VSD Series User Manual

VSD Series Drives User Manual Powered by Eaton Technology
9-4 For more information visit: www.johnsoncontrols.com LIT-1201828
November 2009
Table 9-2: Quick Setup Parameters — M1 ➔ G1.1, continued
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.1.12 Start Srce Hand 1 3 1 112 Parameter for Local
Start/Stop/Reverse control
location.
Default = Keypad
1 = Keypad
2 = DI-1 Start
3 = I/O Three Wire
P1.1.13 StPt Source
Hand
0 3 2 113 Local speed setpoint selection:
0 = analog input AI-1
1 = analog input AI-2
2 = Speed Setpoint from Keypad
3 = Motor Potentiometer
P1.1.14 Start Srce Auto 1 4 2 114 Parameter for Remote Start/
Stop/Reverse control location.
Default = DI-1 Start
1 = Keypad
2 = DI-1 Start
3 = I/O Three Wire
4 = Fieldbus
P1.1.15 StPt Source Auto 0 4 0 115 Remote speed setpoint
selection:
0 = analog input AI-1
1 = analog input AI-2
2 = Speed Setpoint from Keypad
3 = Motor Potentiometer
4 = Speed Setpoint from
Fieldbus
