Table 9-9: Fieldbus Parameters — M1 ➔ G1.8, continued
ID number of parameter or variable to be sent over fieldbus. ID 1 – 20 are Monitoring values, Menu 7 (M7). See Table 9-12.
Preset Speeds — M1
➔
G1.10
Table 9-10: Preset Speeds — M1 ➔ G1.10
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.8.6 FB Data Out6 Sel 0 10000 20
1006 Fieldbus process data output 6
selection.
Default = Application Status
Word (Variable:ApplStatusWord)
b0 = Drive Ready
b1 = Run Enable
b2 = Drive Running
b3 = Drive Reversing
b4 = General Fault
b5 = General Warning
b6 = Preset Speed Active
b7 = Motor Requlator active
b8 = Output speed supervision
indication
b9 = Setpoint speed supervision
indication
b10 = HAND Control indication
b11 = AUTO Control indication
b12 = D-IN Firemode
b13 = Damper control signal
b14 = Bypass mode status
indication
b15 = Bypass running
P1.8.7 FB Data Out7 Sel 0 10000 18
1007 Fieldbus process data output 7
selection.
Default = Active Fault Code
P1.8.8 FB Data Out8 Sel 0 10000 19
1008 Fieldbus process data output 8
selection.
Default = Active Warning Code
Code Parameter Min. Max. Unit Step Default
ID
Number Description
P1.10.1 Preset Speed 1 0 100.0 % 0.1 30.0 1701 Preset speeds when
Digital Inputs are
programmed
P1.10.2 Preset Speed 2 0 100.0 % 0.1 40.0 1702
P1.10.3 Preset Speed 3 0 100.0 % 0.1 50.0 1703
P1.10.4 Preset Speed 4 0 100.0 % 0.1 60.0 1704
P1.10.5 Preset Speed 5 0 100.0 % 0.1 70.0 1705
P1.10.6 Preset Speed 6 0 100.0 % 0.1 80.0 1706
P1.10.7 Preset Speed 7 0 100.0 % 0.1 90.0 1707
