Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828
For more information visit: www.johnsoncontrols.com 5-3
November 2009
Table 5-2: VSD Series Enclosed Drives Selection Chart
All horsepower ratings are Variable Torque (VT).
1 to 60 hp @ 208V; 1 to 75 hp @ 230V; 1 to 150 hp @ 480V; 3 to 100 hp @ 575V
N2/XT/SA Communications selectable on drive keypad.
SA = Sensor Actuator Bus for FEC Interface.
Table 5-3: Options List
IntelliPass only.
Table 5-4: Option Notes
Code Number V S -
Base Product VS = Variable Speed Drive
Prefix
Horsepower (VT)
001 = 1.0 hp to
150 = 150 hp
Voltage 1 = 208V
2 = 230V
4 = 480V
5 = 575V
Enclosure Rating 1 = TYPE 1
2 = TYPE 12
3 = TYPE 3R
Enclosure Style 2 = Enclosed IntelliPass
3 = Enclosed Drive w/Disconnect (IntelliDisconnect)
Revision Number A = Rev 1 (Americas)
Separator (–)
Communications
0 = None
N = N2/XT/SA
Bus Comm (N2 by default)
L = L
ONWORKS
®
Network
Option 1
See Options List
Option 2
See Options List
Option Description
00 None
P3 Line Fuses (formerly Drive Isolation Fusing) — Provides high-level fault protection of the
input power circuit from the load side of the fuses to the input side of the power transistors.
The option consists of three 200 kA fuses, which are factory mounted in the enclosure.
P6
Third Contactor Drive Isolation — Provides load side isolation to the drive in the event of an
SCR or DC Bus failure, allowing the drive to go into bypass without tripping the circuit
breaker. Typically used in critical applications or when required in a specification.
P9
Line Fuses & Third Contactor
SA Space Heater w/Transformer — Prevents condensation from forming in the enclosure when
the drive is inactive or in storage. Includes a thermostat for variable temperature control.
All VSD Series IntelliPass Drives incorporate two factory-installed Auxiliary Contacts
(formerly the K9 option).
P3 Line Fuses Line Fuses, on load side of breaker in both drive and bypass modes
Always included in the part number for 575V Enclosed IntelliPass Drives
P9 Line Fuses &
Third Contactor
Mutually exclusive from Option P3 (Line Fuses) in 575V Enclosed
IntelliPass Drives
SA Space Heater
w/Transformer
Only available for TYPE 3R (Enclosure Rating 3).
