Johnson Controls VSD Series User Manual

Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828 For more information visit: www.johnsoncontrols.com 9-11
November 2009
Prohibit Frequencies— M1 ➔ G1.5
Table 9-6: Prohibit Frequencies — M1 ➔ G1.5
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.5.1 SkipF1 Low Lim 0.0 100.0 % 0.0 501 Prohibit speed range 1 low limit.
P1.5.2 SkipF1 High Lim Range_1_
Low_Lim
100.0 % 0.0 502
Prohibit speed range 1 high limit:
0 = No prohibit frequency range
P1.5.3 SkipF2 Low Lim 0.0 100.0 % 0.0 503 Prohibit speed range 2 low limit
P1.5.4 SkipF2 High Lim Range_2_
Low_Lim
100.0 % 0.0 504
Prohibit speed range 2 high limit:
0 = No prohibit frequency range
P1.5.5 SkipF3 Low Lim 0.0 100.0 % 0.0 505 Prohibit speed range 3 low limit
P1.5.6 SkipF3 High Lim Range_3_
Low_Lim
100.0 % 0.0 506
Prohibit speed range 3 high limit:
0 = No prohibit frequency range
P1.5.7 SkipF4 Low Lim 0.0 100.0 % 0.0 507 Prohibit speed range 4 low limit
P1.5.8 SkipF4 High Lim Range_4_
Low_Lim
100.0 % 0.0 508
Prohibit speed range 4 high limit:
0 = No prohibit frequency range
P1.5.9 SkipF5 Low Lim 0.0 100.0 % 0.0 509 Prohibit speed range 5 low limit
P1.5.10 SkipF5 High Lim Range_5_
Low_Lim
100.0 % 0.0 510
Prohibit speed range 5 high limit:
0 = No prohibit frequency range
P1.5.11 SkipF6 Low Lim 0.0 100.0 % 0.0 511 Prohibit speed range 6 low limit
P1.5.12 SkipF6 High Lim Range_6_
Low_Lim
100.0 % 0.0 512
Prohibit speed range 6 high limit:
0 = No prohibit frequency range
P1.5.13 PH Acc/Dec
Ramp
0.1 10.0 x 1.0 513 Acceleration/Deceleration time
factor to pass prohibit speed
window.
