Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828 For more information visit: www.johnsoncontrols.com A-9
November 2009
Figure A-8: VSD Series Open Drive Dimensions, TYPE 1 and TYPE 12 with Flange Kit, FR4, FR5 and FR6
Table A-6: Dimensions for VSD Series Open Drive, FR4, FR5 and FR6 with Flange Kit
Table A-7: Dimensions for the Flange Opening, FR4 to FR6
Frame
Size Voltage hp (VT)
Approximate Dimensions in Inches (mm)
W1 W2 H1 H2 H3 H4 H5 D1 D2 Dia. A
FR4 230V 1 – 3 5.0
(128)
4.5
(113)
13.3
(337)
12.8
(325)
12.9
(327)
1.2
(30)
.9
(22)
7.5
(190)
3.0
(77)
.3
(7)
480V 1-1/2 – 7-1/2
FR5 230V 5 – 10 5.7
(144)
4.7
(120)
17.0
(434)
16.5
(420)
16.5
(419)
1.4
(36)
.7
(18)
8.4
(214)
3.9
(100)
.3
(7)
480V 10 – 20
FR6 230V 15 – 20 7.7
(195)
6.7
(170)
22.0
(560)
21.6
(549)
22.0
(558)
1.2
(30)
.8
(20)
9.3
(237)
4.2
(106)
.3
(7)
480V 25 – 40
575V 3 – 30
Frame
Size Voltage hp (VT)
Approximate Dimensions in Inches (mm)
W3 W4 W5 H6 H7 H8 H9 Dia. B
FR4 230V 1 – 3 4.8
(123)
4.5
(113)
— 12.4
(315)
12.8
(325)
—.2
(5)
.3
(7)
480V 1-1/2 – 7-1/2
FR5 230V 5 – 10 5.3
(135)
4.7
(120)
— 16.2
(410)
16.5
(420)
—.2
(5)
.3
(7)
480V 10 – 20
FR6 230V 15 – 20 7.3
(185)
6.7
(170)
6.2
(157)
21.2
(539)
21.6
(549)
.3
(7)
.2
(5)
.3
(7)
480V 25 – 40
575V 3 – 30
W2
H1
H2
D2
Flange Opening
FR4 to FR6
H4
H5
H3
W1
Dia. A
D1
W3W4
W5
Dia. B
H7
H6
H9H8
