Johnson Controls VSD Series User Manual

Powered by Eaton Technology VSD Series Drives User Manual
LIT-1201828 For more information visit: www.johnsoncontrols.com 13-13
November 2009
Protections — M1 ➔ G1.7
Table 13-8: Protections — M1 ➔ G1.7
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.7.1 Input Phase
Supv
0 2 2 701 Response to input phase
supervision.
0 = No Action
1 = Warning
2 = Fault
P1.7.2 4mA Fault Resp 0 2 0 702 Response to 4 mA signal
supervision.
0 = No Action
1 = Warning
2 = Fault
P1.7.3 Ext. Fault Resp 0 2 2 703 Response to external fault digital
input signal supervision.
0 = No Action
1 = Warning
2 = Fault
P1.7.4 FBComm.
FaultResp
0 2 0 704 Response to fieldbus
communication supervision.
0 = No Action
1 = Warning
2 = Fault
P1.7.5 SlotComFault
Resp
0 2 0 705 Response to slot communication
supervision.
0 = No Action
1 = Warning
2 = Fault
P1.7.6 Motor Therm
Prot
0 3 0 707 0 = No response
1 = Warning
2 = Fault, stop mode after fault
according to ID402
3 = Fault, stop mode after fault
always by coasting
P1.7.7 MotAmbTemp
Factor
-100.0 100.0 % 0.0 708 Percent of ambient temperature.
P1.7.8 MTP f0 Current 0.0 150.00 % 40.0 709 Percent of motor nameplate
current.
P1.7.9 MTP Motor T 1 200 min 45 710 Time to reach 63% of final value.
P1.7.10 Motor Duty
Cycle
0 100 % 100 711 Percent of nominal motor load
P1.7.11 Stall Protection 0 3 0 712 0 = No response
1 = Warning
2 = Fault, stop mode after fault
according to ID402
3 = Fault, stop mode after fault
always by coasting
P1.7.12 Stall Current 0.00 Motor
CurrentMax
A 1.00 713
P1.7.13 Stall Time Lim 1.00 120.00 s 15.00 714
P1.7.14 Stall Freq Lim 1.00 Max_Freq Hz 25.00 715
