Monitoring Menu — M7
The monitored items are the actual values of parameters and signals as well as the status
and measurements of other elements. Monitored items cannot be edited.
See Chapter 6 — Menu information item M7, for more information.
Table 11-13: Monitoring Menu
Code Parameter Min. Max. Unit Default
ID
Number Description
V7.1 Output
Frequency
-320.00 320.00 Hz 0.00 2 Output frequency to the motor
V7.2 Actual Speed -320.0 320.0 % 0.0 1 Output speed to the motor
V7.3 Speed Setpoint -320.0 320.0 % 0.0 3 Monitored speed setpoint. This
will show also the speed
setpoint below the minimum
frequency.
V7.4 Motor Speed -10000 10000 rpm 0 4 Calculated motor speed in rpm
V7.5 Motor Current 0.0 Motor
CurrentMax
A 0.0 5
V7.6 Motor Torque -300.0 300.0 % 0.0 6 [R] Motor torque as % value,
+1000 equals +100.0 %
pos = clockwise,
neg = counterclockwise
V7.7 Motor Power -300.0 300.0 % 0.0 7
V7.8 Motor Voltage 0.0 1000.0 V 0.0 8 Measured motor voltage
V7.9 DC-Bus Voltage 0 1000 V 0 9 [R] DC voltage in Volts Tfilt =
32ms.
V7.10 Unit
Temperature
-1000 1000 °F 0 10 Temperature of the heat sink
V7.11 Motor
Temperature
0.0 1000.0 % 0.0 11
V7.12 (A) AI-1 -10.00 20.00 V 0.00 12 Voltage Input value [V]
V7.13 (A) AI-2 -10.00 20.00 mA 0.00 13 Current Input value [mA]
V7.14 DI-1 DI-2 DI-3 0 7 0 14 DIA-1, DIA-2 and DIA-3 status
V7.15 DI-4 DI-5 DI-6 0 7 0 15 DIB-4, DIB-5 and DIB-6 status
V7.16 DO-1 RO-1 RO-2 0 7 0 16 DO-1, RO-1 and RO-2 status
V7.17 (A) AO-1 0.00 20.00 mA 0.00 17
V7.18 ActFaultCode 0 200 0 18 Active Fault code.
V7.19 ActWarnCode 0 200 0 19 Active Warning code.
