Table 11-9: Fieldbus Parameters — M1 ➔ G1.8, continued

ID number of parameter or variable to be sent over fieldbus. ID 1 – 20 are Monitoring values, Menu 7 (M7). See Table 11-13.
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.8.6 FB Data Out6 Sel 0 10000 20 1006 Fieldbus process data output 6
selection.
Default = Application Status
Word (Variable:ApplStatusWord)
b0 = Drive Ready
b1 = Run Enable
b2 = Drive Running
b3 = Drive Reversing
b4 = General Fault
b5 = General Warning
b6 = Preset Speed Active
b7 = Motor Regulator active
b8 = Output speed supervision
indication
b9 = Setpoint speed supervision
indication
b10 = HAND Control indication
b11 = AUTO Control indication
b12 = D-IN Firemode
b13 = Damper control signal
b14 = Bypass mode status
indication
b15 = Bypass running
P1.8.7 FB Data Out7 Sel 0 10000 18

1007 Fieldbus process data output 7
selection.
Default = Active Fault Code
P1.8.8 FB Data Out8 Sel 0 10000 19

1008 Fieldbus process data output 8
selection.
Default = Active Warning Code
