Table 9-3: Input Signals — M1 ➔ G1.2, continued
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.2.8 (A) DI-5 Funct. 0 17 9 207 Default #9 Fire-Mode
0 = Not Used
1 = Ext. fault, closing contact
2 = External fault, opening
contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
P1.2.9 (A) DI-6 Funct. 0 17 0 208 Default #0 Overload Fault
Relay-input
0 = Overload Fault Relay input.
(Used in Intellipass)
1 = Ext. fault, closing contact
2 = External fault, opening
contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
P1.2.10 (A) AI-1 Invert 0 1 0 209 0 = Not inverted
1 = Inverted
P1.2.11 (A) AI-1 Filter 0.00 10.00 s 0.10 210 0 = No filtering
P1.2.12 (A) AI-2 Range 0 1 1 211 Default =1 (4-20mA) (0 – 100%)
0 = 0 - 20 mA
1 = 4 - 20 mA
P1.2.13 (A) AI-2 Invert 0 1 0 212 0 = Not inverted
1 = Inverted
P1.2.14 (A) AI-2 Filter 0.00 10.00 s 0.10 213 0 = No filtering
P1.2.15 StPt. Scale Min 0.0 100.0 % 0.0 214 Speed that corresponds to the
minimum setpoint signal.
