Table 9-4: Output Signals — M1 ➔ G1.3, continued
Code Parameter Min. Max. Unit Default
ID
Number Description
P1.3.6 (A) DO-1 Funct. 0 26 1 306 Default=Drive Ready
0 = Not used
1 = Drive Ready
2 = Drive Running
3 = General Fault
4 = General Fault inverted
5 = Drive overheat warning
6 = External fault or warning
7 = Reference (4mA) fault or
warning
8 = General Warning
9 = Drive Reversing
10 = Preset Speed Active
11 = Speed setpoint=Actual
Speed (=At speed)
12 = Motor regulator activated
13 = Actual Speed limit
supervision
14 = Speed Setpoint limit
supervision
15 = Torque limit supervision
16 = Timer On/Timer Off output
control (Trigger is run request)
17 = Selections #16 inverted
18 = Frequency converter
temperature limit supervision
19 = Unrequested rotation
direction
20 = Thermistor fault / warning
21 = Hand Control Active
22 = Auto Control Active
23 = DI-Fire Mode Active
24 = Relay to energize an
external element before starting
the drive.
25 = Fieldbus Passthrough
26 = Bypass Run
P1.3.7 (B) RO-1 Funct. 0 25 2 307 Same as parameter 1.3.6.
P1.3.8 (B) RO-2 Funct. 0 25 3 308 Same as parameter 1.3.6
P1.3.9 (D) RO-1 Funct. 0 25 0 309 Same as parameter 1.3.6
P1.3.10 (D) RO-2 Funct. 0 25 0 310 Same as parameter 1.3.6
P1.3.11 (D) RO-3 Funct. 0 25 0 311 Same as parameter 1.3.6
P1.3.12 Sp.StPt Supv Fct 0 2 0 312 Speed Setpoint Supervision
Function:
0 = Not used
1 = Low limit
2 = High limit
P1.3.13 Sp.StPt Supv
Lim
0.0 100.0 % 0.0 313 Speed Setpoint Supervision
Value.
