8 – 11
8.3
Table 8.5 Special Parts
Parts No. Parts Name Type Maker Location Code
V201 (10 kW) Magnetron MSF1425B New JRC Scanner unit 5VMAA00051
V201 (25 kW) Magnetron M1437 (A) New JRC Scanner unit 5VMAA00074
A101 Circulator FCX68 Toshiba Scanner unit 5AJAA00004
A103 Diode limiter NJS6928 New JRC Scanner unit 5EZAA00019
A102 Pin attenuator NJS6926 New JRC Scanner unit 5ENAC00019
Table 8.6 Circuit Blocks for Repair
Location Circuit block name Type Remark
Scanner unit (10 kW)
Motor with gear MPEM30076
Scanner unit (25 kW)
Motor with gear MPEM30078
Scanner unit (10 kW)
Modulator NMA-469A Including PC201
(CME-261A)
Scanner unit (25 kW)
Modulator NMA-470-1 Including PC210
(CPA-209) and
excluding magnetron.
Scanner unit Receiver NRG-210A PC301 (CAE-344-3)
Scanner unit Interface circuit CMH-1562A PC101
Display unit Power supply unit CBD-1448 PC5101
Display unit Power converter CBA-313 PC5102
Display unit Terminal board circuit CQD-1651 PC4301
Display unit NSK circuit CMJ-304C PC4201
Display unit CPU control circuit CMC-1055B PC4401
Display unit Time base circuit CED-44B PC4402
Display unit Panel circuit-1 CCK-816 PC4501
Display unit Panel circuit-2 CCK-817 PC4502
Display unit Panel circuit-3 CCK-790E PC4503
Display unit Relay circuit CSC -581 PC4701
Display unit ATA circuit CDC-1013 PC4403 (optional)
Display unit Mother board circuit CFQ-8945 PC4101
Display unit Monitor unit 7WZRD0040
Display unit FAN B1 at CQC-951
