JRC JMA-7710-6 User Manual

2
2 – 18
2.2
INIT SET #4
1. MAINTENANCE MENU (STBY)
2. DIAGNOSTIC #1 MENU
3. DIAGNOSTIC #2 MENU (STBY)
DIAGNOSTIC 2
1. MEMORY TEST (STBY)
2. KEY SWITCH TEST (STBY)
SENSOR TEST
SAFETY SWITCH
BEARING PULSE (BP)
BEARING PULSE (BZ)
LINE TEST
NSK
UART 1
UART 2
ATA
ATA STATUS
TRACKING NUMBER
TD INTERRUPT NUMBER
GZ NUMBER
ROM VERSION
MAIN CPU
NSK
ATA CPU
ATA TD
ERROR LOGGING
XXXXXXXXXX
XXXXXXXXXX
c
MAINTENANCE MENU
0. PREVIOUS MENU
1. ANTENNA HIGHT
2.
3. ANTENNA SWITCH
4. PARTIAL MASTER RESET
5. ALL MASTER RESET
6.
INTERNAL SETTING to CARD 2
7. CARD 2 to INTERNAL SETTING
8. MEMOLIZE USER SETTING
9. RESTORE USER SETTING
DIAGNOSTIC 1
1. SENSOR TEST
2. LINE TEST
3. ATA STATUS
4. ROM VERSION
5. ERROR LOGGING
MAG I.
RUNNING TIME
TX TIME
MEMORY TEST
0. PREVIOUS MENU
1. SRAM
2. GRAPHIC RAM
3. FLASH ROM
4. ATA COMMON RAM
5. CARD 1
6. CARD 2
KEY SWITCH TEST
0. PREVIOS MENU
KEY
TRACK BALL
VOLUME
SHAFT ENCODER
ROTARY SWITCH
DIPSW1
DIPSW2
z
v
b
c
.
x
z
x
z
x
Note
● When items are shown on more than one pages,
“PREV” and “NEXT” will be displayed on the upper
right corner of the screen.
● In this case, press the
9
key to display the next
menu or the
0
key to display the previous menu.
(Format is the same as above.)
