3-4
3
3.1.2 Observe and Adjust Video
Procedures 1 Press [RANGE+] key or [RANGE-] key to set the range to the scale
required for target observation.
2 Turn the dials [GAIN], [SEA], and [RAIN] to obtain the clearest targets.
Refer to
[GAIN]→Section “3.2.4 Adjust Gain”
[SEA]→Section “3.2.5 Suppress Sea Clutter”
[RAIN]→Section “3.2.6 Suppress Rain/Snow Clutter”
for how to use each dial.
For how to adjusting video, see Section “3.2 OBSERVE AND ADJUST VIDEO”.
3.1.3 Acquire and Measure Data
For details on how to acquire data and measure, see Section “4 MEASUREMENT OF
RANGE AND BEARING"
3.1.4 Display and Measure with Reference to CCRP
The radar video, range, bearing, Target Tracking and AIS data display etc... are displayed with reference
to CCRP (Consistent Common Reference Point).
If scanner is switched, measure data work the same way.
If some kind of functions set to scanner position is 60% or more outside of the PPI range (example: Off
Center TM Mod etc.), the function switching display with reference to scanner position.
For how to setting CCRP, see the section “7.1.9 Setting of CCRP”.
