Specifications
11.11 DISPLAY UNIT (NCD-2096)
(1) Dimensions : Width 700 x Depth 850 x Height 1100 (mm)
(2) Structure : Self-Standing, Drip Proof
(3) Mass : Approx. 150kg
(4) Display : 23.1inch Color LCD／LED
1600 x 1200dot (UXGA)
(Effective Diameter, more than 320mm)
Display Color: 32 bit color (16,777,216 colors)
(5) Viewing Distance : 1.0m from the center of Display
(6) Range Scale : 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24,
48 and 96nm
(7) Range Marker : 0.025, 0.05, 0.1, 0.25, 0.25, 0.5, 1, 2, 4,
8 and 16nm
(8) Range Accuracy : Less than 1% of the Range Scale in use,
or 30m whichever is larger
(9) Variable Range Marker : 2 (VRM1/VRM2)
(10) VRM Scale : 0.000 to 100.0nm,
Numerical Indication in 4 digits
(11) Bearing Scale : 360° in 1° step
(12) Off Center : Within 66% of Radius, except 96nm range
(13) Trackball Cursor : Built-in
(Target Range, Relative/True bearing Presentation)
(14) Electronic Bearing Lines : 2 (EBL1/EBL2) (on Center/Floating)
(15) EBL bearing Indication : 000.0° to 359.9°
Numerical Indication in 4 digits
(16) Tuning Indication : Bar graph
(17) Marking Function : Electronic Mark (Maximum 20 points)
(18) Heading Line Indication : Electronic
(19) True Motion Unit : Built in (0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24 and 48nm)
(20) Anti Sea Clutter (SEA) : Manual/AUTO
(21) Anti Rain Clutter(RAIN) : Manual/AUTO
(22) Display mode : North-up / Head-up / Course-up
(23) Trails Indication : Off/0.25/0.5/1/3/6/10/15min and Continues
(24) Video Process (PROC) : Built in (Scan correlation / Remain)
(25) Interference Rejection (IR)
: Built in (Off / Low / Middle / High)
(26) Auto-acquisition Zone (AZ)
: Sector (2)
(27) User Map : Built in, Mark and Line (20,000 points)
(Only with Navigation Equipment is connected)
(28) Self diagnostic function : Built in
(29) Own Ship’s Track Indication
: Built in
(Only with Navigation Equipment is connected)
(30) Parallel Index Line (PI) : Built in
(31) AIS Indication : Built in
Number of Target: Display 300
Activate 300
Association function: Built in
