11-11
(32) Chart Display Function : Displaying Chart
･ENC (S57, S63) ･C-MAP Ed.3
Display Object
① Coastline ② Safety Contour
③ Danger to Navigation , Buoy
④ Land Area ⑤ Depth Contour
⑥ Text
※ Setting ON/OFF individually
Display Color
･64 colors
(33) Route Monitoring :Importing the route plan which was created by the
ECDIS/ECDIS Mode, and monitoring route.
･The distance to the To WPT
･Azimuth Calculation
･Computation of the ETA/TTG by actual ship’s speed
･Route leaving watch
･To WPT arrival watch
･Course difference watch
(34) Danger Detection : Observation of approaching to Safety Contour,
Danger object and Special Area
(35) Interfacing : Slave Display (TRG, VD, BP, BZ)
GPS (IEC61162-1)
LOG (IEC61162-1 / Pulse Log)
GYRO (IEC61162-2 / SYNC / STEP)
AIS (IEC61162-2)
Inter switch (Option)
Radar Buoy
External Alarm output
(36) Receivable Signal
1) Navigation equipment: Longitude/Latitude: GGA > RMC > GNS > GLL
IEC61162-1/2
COG/SOG: RMC > VTG
SPEED: VBW > VHW
Day/Time information: ZDA
Alarm acknowledge: ACK
2) Bearing signal: GYRO-SYNC: 360x, 180x, 90x, 36x (GYRO I/F Unit)
GYRO-STEP: 360x, 180x, 90x, 36x (GYRO I/F Unit)
IEC61162-2
38400bps
: HDT > THS
Minimum value 20Hz over
Recommendation value 50Hz over
3) Speed signal: LOG-SYNC: 360x, 180x, 90x, 30x (GYRO I/F Unit)
LOG-PULSE: 800, 400, 200, 100 (GYRO I/F Unit)
4) Depth: IEC61162-1 DPT > DBS > DBK> DBT
5) Water temperature: IEC61162-1 MTW
6) Current: IEC61162-1 CUR
7) Direction of wind, velocity of wind: IEC61162-1 MWV > MWD
8) AIS: IEC61162-1 VDM, VDO, ALR
9) Acknowledge Contact input (SYSACK, ARPAACK, PWRACK).
