3.12 Using Chart
3.12.3 The Display of the Information of Chart Published
(ENC Issue Status)
Procedures 1 Open the ENC Issue Status menu by performing the menu operation
below.
Chart
→ ENC Issue Status
The ENC Issue Status menu will appear.
A cursor mode is set to SENC INFO Read.
2 Left-click the object which wants to display information of doing chart
published.
・ The displayed information is hereinafter.
Chart Type: Chart type
Name: Object name
Date Of Update: Date of update
Number Of Update: Number of update
Issue Number: Issue number
Date of Issue: Date of issue
3.12.4 The Setting of Contour (Contour Setting)
Procedures 1 Open the Contour Setting menu by performing the menu operation
below.
Chart
→ Contour Setting
The Contour Setting menu will appear.
A cursor mode is set to SENC INFO Read.
2 Left-click the items to want to set.
・ The item to set by the value entry is hereinafter.
Shallow Contour
Safety Contour
Safety Depth
Depth Contour
The method of value input is shown in the section “3.3.6 Operation on Numeric
Value, Latitude / Longitude and Character Input menu” for reference.
・ The item to set On/Off are hereinafter.
Tow Color Depth
Shallow pattern
Show Isolated Danger In Shallow Water
