JRC JMA-932B-SA User Manual

1-4
1
1.3 Configuration
y
1.3 CONFIGURATION
Specified of scanner, and categories of ship/craft for SOLAS V
Radar model Antenna type
Transmitted
Output
Power
Band
Rate of
rotation
Category
JMA-933B-SA 12ft Slotted Antenna 30kW S 24rpm CAT 1C
JMA-932B-SA 12ft Slotted Antenna 30kW S 24rpm CAT 1C
7ft Slotted Antenna 25kW X 24rpm CAT 1C
JMA-923B-9XA 9ft Slotted Antenna 25kW X 24rpm CAT 1C
JMA-922B-6XA 6ft Slotted Antenna 25kW X 24rpm CAT 1C
JMA-922B-9XA 9ft Slotted Antenna 25kW X 24rpm CAT 1C
*The class of emission: P0N (All scanner types)
Radar Configuration and Ship’s Mains
Radar model
Scanner
Unit
Performance
Monitor
Transmitter
Receiver
Display Unit Ship’s Mains
JMA-933B-SA NKE-1139 NJU-84 NTG-3230 NCD-2096
JMA-932B-SA NKE-1130 NJU-84 ――― NCD-2096
JMA-923B-7XA NKE-1129-7 NJU-85 NTG-3225 NCD-2096
JMA-923B-9XA NKE-1129-9 NJU-85 NTG-3225 NCD-2096
JMA-922B-6XA NKE-1125-6 NJU-85 ――― NCD-2096
JMA-922B-9XA NKE-1125-9 NJU-85 ――― NCD-2096
AC100 to 115V,
or
AC220 to 240V
50/60Hz 1φ
Accessory list
Name Type Remarks
7ZPRD0694 (Japanese)
RADAR Mode Instruction Manual
7ZPRD0695 (English)
7ZPRD0696 (Japanese)
ECDIS Mode Instruction Manual
7ZPRD0697 (English)
7ZPRD0744 (Japanese)
Simplified Manual
7ZPRD0745 (English)
7ZPNA4111 (Japanese) Additional Manual
for Chart Installation
7ZPNA4112 (English)
Accessory 7ZZNA0426B CD Cleaner
JMA-923B-7XA
