3-29
3.4.7 Move Own Ship’s Display Position (Off Center)
The own ship’s position can be moved from the display center to any position within 66% of the display
radius. This function is convenient for observing a wide coverage in any direction.
If Off Center functions set to scanner position is outside of the PPI range, when function switching
display with reference to scanner position.
Note:
This function is not available on the 96 NM range.
Procedures 1 Left-click the Off Center button located at the upper left of the
display.
The cursor mode becomes the Off Center mode.
2 Move the cross cursor mark (own ship’s display position) to a desired
position by using the trackball.
When a scanner position is over the outside 60% of the display radius, the cross cursor
mark changes to “N/A” and the own ship’s position is not moved.
3 Press the trackball button on the left key.
The own ship’s display position will be fixed to the cross cursor mark.
Returning Own Ship’s Position to the Center
Cancellation 1 Left-click the Off Center button once again.
The own ship position is returned to the center of the display.
