5-55
[VII] Operation of Target Ship's Track Data Saved on HDD (File Operations)
Target ship's track data can be saved on HDD and load from the HDD.
※ Data can be saved to HDD until the data volume becomes full.
Loading File (Load)
Procedures 1 Open the File Operations menu by performing the following menu
operation.
TT
→ Target Track Setting
→ File Operations
2 Select the “Load Mode”.
Add : Selected file is displayed on the radar display with the file
load before.
Overwrite : Selected file is displayed over the file load before.
3 Left-click the loading file.
The left-clicked file is selected.
4 Left-click the Load button.
When “Overwrite” is selected at procedure 2, confirmation window will appear.
Left-click the Yes button.
The selected target track data will be loaded and shown on the radar display.
※ While only transmitting radar, loading file is enabled.
Note:
To select the “Load Mode”, the Display Unit is needed to the install software more
than Ver. 02.00.
