7.2.2 Setting of Bearing Pulses from Antenna (Output Pulse)
Set the output value of bearing pulses from the antenna. The system can set 2048 pulses or 4096 pulses.
Procedures 1. Open the Serviceman Menu.
2. Perform the following menu open procedure to open the Output Pulse
setting menu.
Adjust Menu
→ TXRX Adjustment
→ Output Pulse
3. Left-click the Output Pulse comb box.
2048 : 2048 pulses per antenna rotation (Recommended value)
4096 : 4096 pulses per antenna rotation
7.2.3 Slave Mode Setting (Master/Slave)
Place the system in the Slave mode when it is to be operated as the sub-display that displays radar echoes
by using radar signals from other radar equipment.
The input value of externally input bearing pulses can be set. The system can set 2048 pulses or 4096 pulses.
Procedures 1. Open the Serviceman Menu.
2. Perform the following menu open procedure to open the installation
setting menu.
Installation Menu
3. Select Slave for the item Master/Slave in the menu.
Master : The system operates as radar equipment while the own antenna is connected.
Slave : The system operates as a sub-display while the signal cable of other radar
equipment is connected.
