7-7
7.1.9 Setting of CCRP (CCRP Setting)
Set the own ship's CCRP location, radar antenna installation location, and GPS installation location.
CCRP: Up to four locations can be input. (One location selected when used)
Radar antenna: Up to eight radar antennas can be input. (Automatically selected in response to ISW
operation)
GPS: Up to four locations can be input. (One location selected when used)
Procedures 1. Measure the CCRP location, radar antenna location, and GPS antenna
location in advance.
2. Open the Serviceman Menu.
3. Perform the following menu open procedure to open the CCRP Setting
menu.
Installation Menu
→ CCRP Setting
4. Specify the ship length for Length at the upper right of the CCRP Setting
Menu, and the ship width for Beam.
5. Move the cursor onto the CCRP1 X, Y value, and left-click to input the
CCRP1 location.
When X > 0, the CCRP is on the starboard side of the ship.
When X < 0, it is on the port side.
※ Usually, Chart radar works normally when inputting just CCRP1.
6. If it needs to input the second CCRP, click the CCRP2 button to
display the CCRP2 X,Y value, and input the value in the same manner for
step 5.
Similarly, input the third and subsequent CCRPs.
7. Repeat the above steps to input the GPS location(s) and radar antenna
location(s) for all quantities of installed ones.
8. If multiple CCRP locations are input, left-click to select the used CCRP.
9. Check the checkbox of GPS and radar antenna for all quantities of
installed ones.
10. After setting completion, left-click the OK .
11. When completed the setting change, restart necessarily the power.
