JRC JMA-932B-SA - 3.7 USE ROUTE FUNCTION

3-62
3
3.7 Use Route Function
y
y y
3.7
USE ROUTE FUNCTION
3.7.1 Display Route
Route which created in ECDIS can be displayed.
To display route, create route beforehand and the route data must be copied beforehand.
For information on how to copy the data, see to the section “3.11 USING FILE MANAGER”.
A route created by switched the ECDIS mode can be also displayed with the radar mode.
Procedures 1 Open the Route menu by performing the following menu operation.
Route
The Route menu will appear.
2 Left-click the Route combo box.
3 Left-click the route name to want to display.
The route is displayed.
4 Left-click the To WPT combo box.
5 Left-click destination (WPT) to want to information display.
An azimuth and a distance from own ship position to selected WPT is displayed.
Automatically set which is the nearest from the position and the azimuth of own ship
when select AUTO Select.
