3-97
3.10
USE USER SETTING
The operation status of the radar is recorded. If the system is operated by more than one operator, the
operators can register operation status as suitable for them and call the status. Operation status for up to
five operations can be registered, and a name can be assigned to each status. (Up to 10 alphanumeric
characters)
* Data saved by the user setting
• Display Color Setting menu
• Buzzer Volume
• Option Key Setting menu
• Display Style (Date display style)
• EBL / VRM Control CURS
3.10.1 Save Operating State (Save User Setting)
The system's current operating state can be saved in the system by performing the operation below.
Procedures 1 Open the User Setting menu by performing the menu operation below.
Main
→ Sub Menu
→ User Setting
The User Setting menu will appear.
2 Left-click the list button for the file to be saved.
3 Left-click the Save User Setting.
When the file exists already in the list, select Yes because the dialog of the
overwriting confirmation is displayed.
4 Enter a file name to be saved.
The Input File Name menu will appear.
On the numeric value input screen, enter a file name.
After the file name has been entered, the operating conditions will be saved.
