1.2 Features
y
1.2 FEATURES
Realization of Large, Easy-to-see Screen with High Resolution
The 23.1-inch color LCD with high resolution of 1600 × 1200 pixels can display radar images of 320
mm or more in diameter. Even short-range targets can also be displayed as high-resolution images.
Target Detection by Latest Signal Processing Technology
The system employs the latest digital signal processing technology to eliminate undesired clutter from
the radar video signals that are obtained from the receiver with a wide dynamic range, thus improving
the target detection.
Target Tracking (TT) Function based on Advanced Technology
The target acquisition and tracking performance is enhanced by the use of the fastest DSP and
tracking algorithm. So stable operation in target tracking under clutter is ensured.
• Acquisition and tracking of 100 targets.
• Hazardous conditions are represented by shapes and colors of symbols as well as sounds.
• Trial maneuvering functions are provided.
• Tracks of up to 20 target ships can be stored with a maximum of 1,500 points for each of them, and
displayed distinguished by using eleven different colors.
Overlay of Radar Images, Coastlines, and Own Ship's Track
As well as operator-created NAV lines and own ship's tracks/ARPA tracks, which is stored on the
memory card can be superimpose-displayed with radar images and radar trails in all display modes
including the head-up mode.
Easy Operation with GUI
All the radar functions can be easily controlled by simply using the trackball and two switches to
operate the buttons shown on the radar display.
Improved Day/Night Mode
Five types of background colors are available in Day/Dusk/Night mode (total 5 background colors).
Each background color can be reproduced to be suited for the user’s operating environment by simple
key operation. The radar echoes and a variety of graphics can also be represented in different colors,
ensuring easy-to-see displays.
