4-15
4.1.6 Operating EBL Maneuver Function (EBL Maneuver Setting)
[I] Initial Setting (EBL Maneuver Setting)
Procedures 1 Open the EBL Maneuver Setting menu by performing the following
menu operation.
Main
EBL Maneuver Setting
2 Set the following parameters.
Reach :Sets the range from when the rudder is steered to when the ship beings
to turn.
Turn Mode :Select a turn mode.
Radius :Turning radius (nm)
Rate : Rate of turn (deg/min)
Turn Set :Select the setting for turning.
If Radius is selected :Turning radius (nm)
If Rate is selected :Rate of turn (deg/min)
For inputs to the value input screen, refer to Section “3.3.6 Operation on Numeric Value,
Latitude / Longitude and Character Input menu”.
Note:
A wrong initial setting affects the maneuver curve function explained below.
To Next Page
