3-92
3
3.9 Use Function Key
y
y y
3.9.2 Function Setting Menu Items
The function setting menu has the items below.
Page 1
Page 2
Page 3
Page 4
Page 5
1. Mode Name of the mode to be used Coast/Deepsea/････
2. IR Radar interference rejection Off/Low/Middle/High
3. Process Video process PROC Off/3Scan CORREL/････
4. Target Enhance Target expansion Off/Level1/Level2/Level3
5. AUTO Sea/Rain Automatic clutter suppression Off / AUTO Sea / AUTO Sea/Rain
6. Save Present State Saving of the present state
1. Pulse Length 0.75NM Standard pulse length of 0.75 nm range SP1/MP1
2. Pulse Length 1.5NM Standard pulse length of 1.5 nm range SP1/MP1/MP2/MP3/LP1
3. Pulse Length 3NM Standard pulse length of 3 nm range MP1/MP2/SP1/LP1
4. Pulse Length 6NM Standard pulse length of 6 nm range MP1/MP2/LP1/LP2
5. Pulse Length 12NM Standard pulse length of 12 nm range MP1/MP2/LP1/LP2
1. Video Latitude Dynamic range of radar video Narrow/ Normal /Wide/Super
Wide
2. Video Noise Rejection Radar video noise rejection Off/Level1/Level2
3. AUTO Dynamic Range Automatic dynamic range control Off/On
4. Process Switch Radar video process switching Off/Range FIX/AUTO
5. 2nd Process Mode Second video process mode PROC Off/3Scan CORREL/････
6. Process Switch Range Video process switching range Range setting
7. Fast Target Detection Fast moving target detection Off/On
1. Trails Interval Radar trails length Off/15sec/････
2. Trails Mode Radar trails mode True/Relative
3. Trails REF Level Radar trails plotting threshold Level1-4
4. Trails Reduction Thinning of radar trails Off/Level1-3
5. Trails Process Radar trails video process Off/On
6. Max Interval Maximum time for radar trails display Short/Middle/Long
1. Gain Offset Gain correction Correction value setting
2. PRF Transmitting repetition frequency Normal/Economy/High Power
3. Small Buoy Detection Small target detection mode Off/On
4. Fishnet Detection Fishnet detection mode Off/On
5. Antenna Height Antenna height Under 5m/5-10m/10-20m/20 Over
6. Set Mode Default Set to typical value
7. Initialize Retuned to initial conditions
To Next Page
