JRC JMA-932B-SA User Manual

9-9
9.2.1 Special Parts
Table 9-11 Special Parts
[I] NKE-1125 (JMA-922B-6XA/9XA)
Parts No. Name Type Manufacturer Location Code
V101 Magnetron M1568BS NJRC Scanner unit 5VMAA00106
A101/A102 Circulator NJC3901M NJRC Scanner unit 5AJBV00007
A103 Dummy NJC4002 NJRC
Scanner unit
5ANDF00001
A104 Filter NJC9952 NJRC
Scanner unit
5AWAX00002
A301 Diode Limiter NJS6930 NJRC Scanner unit 5ATBT00006
[II] NTG-3225 (JMA-923B-7XA/9XA)
Parts No. Name Type Manufacturer Location Code
V101 Magnetron M1568BS NJRC Transmitter-Receiver unit 5VMAA00106
A101/A102 Circulator NJC3901M NJRC Transmitter-Receiver unit 5AJBV00007
A103 Dummy NJC4002 NJRC Transmitter-Receiver unit 5ANDF00001
A104 Filter NJC9952 NJRC Transmitter-Receiver unit 5AWAX00002
A301 Diode Limiter NJS6930 NJRC Transmitter-Receiver unit 5ATBT00006
A302 PIN Attenuator NJS6926 NJRC Transmitter-Receiver unit 5ATBT00007
[III] NKE-1130 (JMA-932B-SA)
Parts No. Name Type Manufacturer Location Code
V101 Magnetron M1555 NJRC Scanner unit 5VMAA00104
A101 Circulator NJC3316 NJRC Scanner unit 5AJBV00008
A301 Diode Limiter
NJS6318
NJRC Scanner unit 5ATBT00005
[IV] NTG-3230 (JMA-933B-SA)
Parts No. Name Type Manufacturer Location Code
V101 Magnetron M1555 NJRC Transmitter-Receiver unit 5VMAA00104
A101 Circulator NJC3317 NJRC Transmitter-Receiver unit 5AJBV00009
A301 TR Limiter
TL378A
NJRC Transmitter-Receiver unit 5VLAA00037
