11-6

Specifications

(12) Modulator : Solid State Modulator Circuit

(13) Duplexer : Circulator + Diode Limiter

(14) Front end Module : Built-in

(15) Intermediate Frequency Amplifier

: Intermediate Frequency: 60MHz

Band Width: 25/8/3MHz

Gain: more than 90dB

Amplifying Characteristics: Logarithmic Amplifier

(16) Overall Noise Figure : 7.5dB (Typical)

(17) Tuning : Manual/AUTO

11.7 SCANNER UNIT (NKE-1129-7/9)

(1) Dimensions : 7ft Height 536 x Swing Circle 2270 (mm)

9ft Height 536 x Swing Circle 2825 (mm)

(2) Mass : 7ft Approx. 51kg

9ft Approx. 53kg

(3) Polarization : Horizontal

(4) Directional Characteristics:

Horizontal beam width 7ft 1.0°

9ft 0.8°

Vertical beam width 20°

Side lobe Level below -26dB (within +/-10°)

below -30dB (outside +/-10°)

(5) Revolution : Approx. 24rpm

(6) Power Supply for Motor : AC100 to 115V, 50/60Hz, 1φ or

AC220 to 240V, 50/60Hz, 1φ

(7) Maximum wind Velocity : 51.5m/s (100knots)
