3-79
3.8.12 Set Navigation Data Display (Multi Window Setting)
By performing the following operation, it is possible to display navigation data of the wind direction /
velocity, water depth and the like, as a graph on the radar display.
Procedures 1 Open the Multi Window Setting menu by performing the menu operation
below.
Main
→ Multi Window Setting
The Multi Window Setting menu will appear.
Detailed settings of the display are possible by changing the settings of each item.
[1] DIR/DIST EXP Display
･ Determine whether to expand the value display of cursor, EBL, and VRM.
･ The value display is expanded in digital information area 2.
･ When the cursor mark moves on the PPI, the display of cursor information is expanded.
･ When an EBL or VRM is operated, the value display of each marker is expanded.
･ While the menu is open, any display is not expanded.
Off : Does not expand any display.
On : Expands the display in digital information area 2.
The expanded display remains for 5 seconds after the operation of each
marker, and then it will disappear.
Always On : Expands the display in digital information area 2.
To Next Page
