3-80
3
3.8 Applied Operations
y
y y
[2] Numeric NAV INFO
･ Determine whether to display the numeric values of received navigation information.
･ One of two digital information areas is used to display data.
･ When navigation data is displayed, the sizes of the target tracking (TT)/AIS numeric data display areas
are decreased.
･ Navigation information of the water depth, water temperature, tidal current, wind direction/velocity, and
destination is displayed with numeric values.
･ Left-click the Target button located at the lower right of the display. The navigation data display
function is switched between On and Off.
Off : Does not display the numeric values of navigation information.
Area1 : Displays the numeric values of navigation information in digital information
area 1.
Area2 : Displays the numeric values of navigation information in digital information
area 2.
[3] Depth Graph Setting
･ The Depth Graph Setting menu will appear.
[a] Depth Graph Display
･ Determine whether to display received water depth information with a graph.
･ One of two digital information areas is used to display data.
･ When the water-depth graph is displayed, the sizes of the target tracking (TT)/AIS numeric data display
areas are decreased.
･ Left-click the Target button located at the lower right of the display. The water-depth graph display
function is switched between On and Off.
Off : Does not display a water depth graph.
Area1 : Displays the water depth graph in digital information area 1.
Area2 : Displays the water depth graph in digital information area 2.
[b] Depth Range
･ Select the depth range on the water depth graph.
50 : Sets to 50 m as the depth range.
100 : Sets to 100 m as the depth range.
250 : Sets to 250 m as the depth range.
AUTO : Uses the depth range in the DPT sentence included in received data.
[c] Time Range
･ Select the time range on the water depth graph.
10min : Sets to 10 minutes as the time range.
15min : Sets to 15 minutes as the time range.
30min : Sets to 30 minutes as the time range.
60min : Sets to 60 minutes as the time range.
12hour : Sets to 12 hours as the time range.
To Next Page
