3-81
[d] Depth Unit
･ Set the unit of water depth for the water-depth graph.
Feet : The foot is used as the unit of water depth.
Fathom : The fathom is used as the unit of water depth.
Meters : The meter is used as the unit of water depth.
[e] Depth Display Setting
･ Set the priority level of unit of water depth for the water-depth graph.
AUTO (Surf / Trans / Keel) : Sets the priority level of unit in order as follows
Surf > Trans > Keel
Keel : Sets the priority level of unit「Keel」.
.
[4] Wind Graph Setting
･ The Wind Graph Setting menu will appear.
[a] Wind Graph Display
･ Determine whether to display received wind direction/velocity information with a graph.
･ One of two digital information areas is used to display data.
･ When the wind direction / speed graph is displayed, the sizes of the target tracking (TT) / AIS numeric
data display areas are decreased.
･ Left-click the Target button located at the lower right of the display. The wind direction / speed
graph display function is switched between On and Off.
Off : Non-display the wind direction / speed graph.
Area1 : Displays the wind direction / speed graph in digital information area 1.
Area2 : Displays the wind direction / speed graph in digital information area 2.
[b] Wind Speed Unit
･ Set the unit of wind velocity for the wind direction / speed graph.
m/s : Meters per second are used as the unit of wind speed.
km/h : Kilometers per hour are used as the unit of wind speed.
kn : Knots are used as the unit of wind speed.
[c] Wind Direction (True)
･ Set the wind direction mark (at true) of graph.
16points : The wind direction mark is displayed by 16 direction display.
Degree : The wind direction mark is displayed by angular representation.
Notice:
The display of the wind direction velocity of the wind graph is displayed since radar software version of
display unit 2.00.
