3-82
3
3.8 Applied Operations
y
y y
[5] TEMP Graph Setting
･ The TEMP Graph Setting menu will appear.
[a] TEMP Graph Display
･ Determine whether to display the graph of the water-temperature data that has been received on the
radar display.
･ One of two digital information areas is used to display data.
･ When the water-temperature graph is displayed, the sizes of the target tracking (TT)/AIS numeric data
display areas are decreased.
･ Left-click the Target button located at the lower right of the display. The water-temperature graph
display function is switched between On and Off.
Off : The water-temperature graph is not displayed.
Area1 : The water-temperature graph is displayed in digital information area 1.
Area2 : The water-temperature graph is displayed in digital information area 2.
[b] TEMP Graph Color
･ Set the color for the water-temperature graph.
･ There are eight selection items : White, Cyan, Blue, Green, Yellow, Pink, and Red.
[c] TEMP Range
･ When displaying water-temperature graph, set the temperature range of each color.
[d] Time Range
･ Set the time range for the water-temperature graph.
10min : The time range is set at 10 minutes.
15min : The time range is set at 15 minutes.
30min : The time range is set at 30 minutes.
60min : The time range is set at 60 minutes.
12hour : The time range is set at 12 hour.
Notice:
TEMP graph is displayed since radar software version of display unit 2.00.
