8.4.1 Check Performance on Test Menu
The radar operating state can be checked by opening the Test Menu.
Procedures 1. Perform the following menu open procedure to open the Test Menu.
Main
→ Test Menu
2. Select the items to be checked.
The list of check items will appear.
Self Test Self-diagnostic function
Monitor Test Monitor check
Keyboard Test Operation unit check
Magnetron Current Indication of magnetron current
MON Display Performance monitor
Navigation Alarm Log Navigation alarm log display
System Alarm Log Error log display
System Information System information display
Self-diagnosis function (Self Test)
Checking of memory, scanner unit, and communications Lines
Memory Test [1] Memory check
TXRX Test [2] Scanner check
Line Test [3] Line Test
GPIO Test [4] GPIO Test
System Monitor [5] System Monitor check
[1] Memory Test
Checking for the performance of built-in memory.
When no abnormality is found, “OK” is displayed.
When an abnormality is found, “NG” is displayed.
[2] TXRX Test
Checking for signals from the scanner.
When no abnormality is found, “OK” is displayed.
When an abnormality is found, “NG” is displayed.
In standby, ** will appear.
