3-74
3
3.8 Applied Operations
y
y y
[2] Setting display brilliance (Brilliance Setting)
In each Day/Night mode, this function sets display brilliances background color outside the bearing scale,
color for characters, radar echo and radar trails, etc.
Procedures 1 Open the Brilliance Setting menu by performing the menu operation
below.
Main Menu
→ Sub Menu
→ Brilliance Setting
Display Brilliance Setting menu will appear.
Setting brilliance of each element
･ Specify the brilliance for the element.
･ Level4 indicates maximum brilliance and Level1 indicates minimum brilliance.
･ The brilliance for the following elements can be specified.
Character : The brilliance of the character and bearing scale is
selected.
RADAR Video : The brilliance of the radar video is selected.
RADAR Trails : The brilliance of the radar trails is selected.
Target Symbol : The brilliance of the target symbol is selected.
Range Rings : The brilliance of the range rings is selected.
EBL / VRM / PI : The brilliance of the EBL / VRM / PI is selected.
Own Symbol / HL / Vector : The brilliance of the own ship symbol, heading line, and
own ship vector is selected.
Keyboard : The brilliance of the operation panel is selected.
Note:
Those selected brilliance can be saved for each Day/Night mode.
[3] Setting radar video brilliance (VID)
The brilliance of the video on the radar display is adjusted.
Procedures 1 Left-click the VID button located at the lower right of the radar
display, and adjust the brilliance of the radar video so as to get the best
view of the video display.
The brilliance of the radar video can be adjusted on four stages without opening the
Brilliance Setting menu.
Adjust the radar display to obtain the best-to-view video.
To Next Page
