3-102
3
y
y y
3.11 Using File Manager
[III] Delete the file (Delete)
Procedures 1 Left-click the Type combo box in the condition that the file manager was
open.
2 Left-click the item of the type to want to delete.
3 Left-click the destination 1 combo box.
4 Left-click Local Disk of the list.
5 Left-click the file name to want to delete.
6 Left-click the Delete button.
The dialog of the confirmation of the deletion execution is displayed.
When deleting, click the OK .
A file is deleted.
[IV] Remove the USB Device
Procedures 1 Left-click USB icon displayed in the upper-right corner of the
screen.
Note: When connected a USB device, the USB icon is displayed on the upper-right of the
screen.
2 Select the device that removes, then left-click Yes .
3 Left-click OK .
USB icon disappears.
Remove the devices after disappearing icon.
Notice:
USB icon is displayed since radar software ver., 2.00.
To Next Page
